Pressing force | 300 tons |
---|---|
Electrical power | 22kw/30hp |
Control system | PLC control |
Max. operating pressure | 200-220 bar |
Top platen size | 1400 x 600 mm |
Bottom platen size | 1520 x 660 mm |
No. of cycles | 70-80 / hour |
Shipping dimensions | 5.5 x 3 x 1.5 meter |
Approx. weight | 15 tons |
